PHD200
Post Hole Diggers
- Dependable, rugged gearbox
- Safety shielding covers auger and power take-off
- Optional downforce kits
- Optional hook-up stand
View Product Brochure
Features
PHD0 Series Post Hole Digger gearboxThe PHD0 Series Post Hole Digger has a rugged and dependable gearbox for a longer-lasting life.
PHD0 Series Post-Hole Digger safety shieldThe PHD0 Series Post-Hole Diggers have a strong safety shield surrounding the auger and PTO to provide extra protection and longer life.
The downforce kits are for post hole diggers as identified below.
NOTE: The downforce kit requires hydraulic pressure from a tractor selective control valve (SCV) and a pressure-free return.
The auger position handle allows the operator to place the post-hole digger in the correct position before digging.
The field conversion auger position handle kit can be installed on PHD300 and PHD400 Series Post-Hole Diggers.
Great for mounting, dismounting, and storageThe foldable hook-up stand allows operators to easily mount and dismount the post-hole digger from the tractor. The stand has several adjusting height options to accommodate the operator's needs.
The stand is ideal for storing the post-hole digger safely and prolongs the implement's life by keeping it off the ground.
Specifications
Compare the specifications of up to 4 models
| Dimensions | PHD200 Current Model |
|---|---|
| Boom OD | 8.9 cm 3.5 in. |
| Yoke OD | 7.9 cm 2.875 in. |
| Auger speed | |
| rpm | 180 rpm |
| Gearbox | |
| Gear ratio | 3:1 |
| Tractor compatibility | |
| Gearbox hp rating | 29.8 kW 40 hp |
| PTO hp range | 13.4-29 kW 18-40 hp |
| 3-Point hitch | |
| Category | 1 |
| Auger compatibility | |
| Model number | PHA106, PHA109, PHA112 |
| Weight | |
| Unit | 90.7 kg 200 lb |
| Shipping (2 per case) | 213.2 kg 470 lb |
| Set-up time | |
| Labor hours | |
| Warranty | |
| Time period |
